| Video Input |
| Interfaces |
2 x HDMI Type A Female (Black) |
| Impedance |
100 Ω |
| Max. Distance |
5 m |
| Video Output |
| Interfaces |
2 x HDMI Type A Female (Black) |
| Impedance |
100 Ω |
| Max. Distance |
15 m |
| Video |
| Max. Data Rate |
10.2 Gbps (3.4 Gbps Per Lane) |
| Max. Pixel Clock |
340 MHz |
| Compliance |
HDMI (3D, 4K, Deep Color)
HDCP 1.4 Compatible
Consumer Electronics Control (CEC) |
| Max. Resolution |
Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:2:0);
4096 x 2160 / 3840 x 2160 @ 30Hz (4:4:4) |
| Max. Distance |
Up to 15 m |
| Control |
| USB |
1 x Micro USB
F/W upgrade |
| RS-232 |
Connector: 1 x DB-9 Female (Black)
Baud rate and protocol:
Baud Rate: 19200, Data Bits: 8, Stop Bits:1, Parity: No, Flow Control: No |
| IR |
1 x Mini Stereo Jack Female (Black) |
| EDID Settings |
EDID Mode: Default / Port1 / Remix |
| Carton Lot |
5 pcs |
| Physical Properties |
| Weight |
0.58 kg ( 1.28 lb ) |
| Housing |
Metal |
| Dimensions (L x W x H) |
20.00 x 7.60 x 4.20 cm
(7.87 x 2.99 x 1.65 in.) |
| Connectors |
| Power |
1 x DC Jack (Black) |
| Power Consumption |
DC5V:4.3W:20BTU/h
Note:
● The measurement in Watts indicates the typical power consumption of the device with no external loading.
● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded. |
| Environmental |
| Operating Temperature |
0-40°C |
| Storage Temperature |
-20 – 60°C |
| Humidity |
0 – 80% RH, Non-Condensing |
| Note |
For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format. |
